TECHNICAL DATA
Peak power: 400 W
RMS power: 200 W
Woofer: ø 200 mm – 8”
Silk dome tweeter: ø 25 mm voice coil
Frequency response (Hz): 40-20.000
Dimensions WxDxH (cm): 35x33x37,5
Weight (Kg): 11,3 (protection bag included)
MAIN FEATURES
4 input channels:
1 balanced or unbalanced input with a Jack 6,3 to connect a guitar
2 balanced or unbalanced inputs with and XLR jack to connect a dynamic or a condenser microphone or with a 6,3 jack to connect other guitars or instruments.
1stereo input with 2 RCA connectors to connect an external source (CD or DVD player) or one 3,5 jack to connect an external source (iPod, MP3, Smartphone, Tablet, PC or a laptop)
Signal processing:
Every mono channel has the possibility to:
Adjust input gain
Adjust high-mid-low +/- 15 dB
Adjust signal level to effects
Adjust signal level to amplifier
Other settings are possible on the mixed signal:
Choose effects to apply to all inputs – 16 possibilities operated by DSP
Adjust general effects level
Apply and adjust NOtch Filter (*) frequency
Adjust signal amplification
4 outputs:
STEREO OUT: stereo output to connect and external recorder. Level is set by the specific control
LINE OUT / DI OUT BALANCED: are mono balanced outputs to connect a mixer, an active speaker or an amplifier; level is set by the specific control. This output is mono so, signal from stereo inputs are mixed together
PHONES: stereo output for headphones: level is set both by STEREO OUT control and PHONES level control. The channel is post fader and consequently all settings made on each channel and all effects are present. These independent outputs can assure a great versatily of use. For example, you can keep volume to zero and listen with the headphones all that has been connected. You have the possibility to record what ou are playing, adjusting independently recording volume from headset volume or even use the product as monitor and connect it to a bigger system.
