High-quality handheld stereo recording
Small size and easy operation
Micro SD/SDHC/SDXC cards can be used as recording media (up to 128 GB)
Supported audio formats:
Linear PCM (WAV format) at 44.1 kHz / 16 bit (CD quality) or 44.1 kHz / 24 bit
Linear PCM (WAV format), 48 kHz / 24 bit
Linear PCM (WAV format), 96 kHz / 24 bit
Compressed (MP3 format): 32–320 kbit/s at 44.1/48 kHz (VBR files can be played but not recorded)
NEW: Can be used as a USB audio interface with Mac and Windows computers (two inputs, two outputs)
Recording
Built-in omni-directional stereo condenser microphone for lively, high-quality sound and high-resolution recording
Easy setup
Proven high sound pressure design for capturing sounds of up to 125 dB SPL, making it ideal for loud band recordings
Natural sound independent of the sound source’s position
Ideal for live music recording or news gathering with atmo
Switchable filter to minimize unwanted low-frequency noise (40 Hz, 80 Hz, 120 Hz)
Manual recording level setting for music and field recording
Three options of automatic level control during recording: Peak Reduction, Auto Level, Limiter
Auto-recording function to automatically start recording based on input level
Marks can be added automatically when using the automatic recording function
NEW: Overwrite function for punch-in recording with one level of Undo
NEW: Dictation mode designed for human voice recording and transcription
Pre-recording buffer (2 seconds) allows a recording to start before the record key is pressed
Self-timer allows a recording to start 5 or 10 seconds after pressing the RECORD button
A new file can be created manually during recording or automatically when a certain file size is reached
Set marks to quickly locate certain audio positions (up to 99 per file)
Automatic tone generator convenient when editing with video on other equipment
Stereo mic/line input with plug-in power to connect an external source or microphone
File name format can be set to use a predefined word or the date
Playback
Automatic level align prevents uneven playback levels
Variable speed audition to change the playback tempo without affecting the key (50–200 %)
Repeat/loop function (repeat one track, all tracks or a marked section, convenient for practicing music and studying languages
Playlist feature to play files in a certain order
Resume function retains the last stop position and starts playback from that position when power is turned back on
Jump back function to instantly review playback (1–10, 20, 30 seconds)
Equalizer for tone control during playback
MP3 ID3 tag display (up to version 2.4)
Built-in loudspeaker
Headphones/Line output
Other features
QUICK menu button for easy access to various functions
Chromatic tuner function to tune your instrument
File divide function to cut unwanted noise or to extract parts from long recordings
Folder management to organize your files
Hold function to avoid inadvertent operation
Menu language can be selected between English, German, French, Italian, Spanish, Portuguese, Russian, Korean, Japanese, Chinese
Clear, backlit LC display
USB 2.0 port for file transfer to/from computer
Power supply by 2 AA size Alkaline or NiMH batteries, USB bus power or optional AC adapter (Tascam PS-P520E)
Stand adapter (¼ inch) on bottom side to attach the unit to a tripod or microphone stand
Supported operating systems
Windows
Windows 10 (May 2019 Update) Windows 10 (October 2018 Update) Windows 10 (April 2018 Update) Windows 8.1 Windows 7
Mac
macOS Mojave macOS High Sierra (10.13) macOS Sierra (10.12)
iOS
iOS 12 iOS 11
Specifications
General
Recording media microSD card (64 MB – 2 GB)
microSDHC card (4–32 GB)
microSDXC card (48–128 GB)
Recording/playback formats WAV: 44.1/48/96 kHz, 16/24 bit
MP3: 44.1/48 kHz, 32/64/96/128/192/256/320 kbit/s
Number of channels 2 channels (stereo)
Inputs and outputs
External Mic input (can provide plug-in power) 3.5-mm stereo mini jack
Headphones / Line output 3.5-mm stereo mini jack
Built-in loudspeaker 0.3 W (mono)
Control input/output
USB port Micro-B connector
Format USB 2.0 High Speed mass storage class
Audio performance
Frequency response 20 Hz – 20 kHz +1/−3 dB
(MIC/EXT IN to LINE OUT, Fs 44.1 kHz, JEITA)
20 Hz – 22 kHz +1/−3 dB
(MIC/EXT IN to LINE OUT, Fs 48 kHz, JEITA)
20 Hz – 40 kHz +1/−3 dB
(MIC/EXT IN to LINE OUT, Fs 96 kHz, JEITA)
Total harmonic distortion ≤0.05 %
(MIC/EXT IN to LINE OUT, Fs 44.1/48/96 kHz, JEITA)
S/N ratio ≥92 dB
(MIC/EXT IN to LINE OUT, Fs 44.1/48/96 kHz, JEITA)
Note: JEITA indicates compliance with JEITA CP-2150
Approximate battery operation time (continuous operation)
Alkaline batteries (Evolta)
WAV, 96 kHz, 24 bit 15:30 (recording with built-in mics)
WAV, 44,1 kHz, 16 bit 17:30 (recording with built-in mics)
MP3, 44,1 kHz, 128 kbit/s 16:30 (recording with built-in mics)
MP3, 48 kHz, 320 kbit/s 11:00 (recording with built-in mics)
WAV, 96 kHz, 24 bit 14:00 (playback using headphones or built-in speaker)
WAV, 44,1 kHz, 16 bit 16:30 (playback using headphones or built-in speaker)
MP3, 44,1 kHz, 128 kbit/s 16:30 (playback using headphones or built-in speaker)
MP3, 48 kHz, 320 kbit/s 15:30 (playback using headphones or built-in speaker)
NiMH rechargeable batteries (Eneloop)
WAV, 96 kHz, 24 bit 12:30 (recording with built-in mics)
WAV, 44,1 kHz, 16 bit 14:30 (recording with built-in mics)
MP3, 44,1 kHz, 128 kbit/s 13:00 (recording with built-in mics)
MP3, 48 kHz, 320 kbit/s 10:00 (recording with built-in mics)
WAV, 96 kHz, 24 bit 13:00 (playback using headphones)
12:00 (playback using built-in speaker)
WAV, 44,1 kHz, 16 bit 14:00 (playback using headphones)
15:00 (playback using built-in speaker)
MP3, 44,1 kHz, 128 kbit/s 13:30 (playback using headphones)
13:00 (playback using built-in speaker)
MP3, 48 kHz, 320 kbit/s 13:30 (playback using headphones)
13:00 (playback using built-in speaker)
Power supply and other specifications
Power requirements 2 AA batteries (alkaline or NiMH)
USB bus power from a computer
AC adapter (Tascam PS-P520E, sold separately)
Power consumption 1.7 W (maximum)
Dimensions (W × H × D) 61 mm × 141 mm × 26 mm
Weight 119 g (without batteries)
165 g (with batteries)
Permissible operating temperature range 0–40 °C
